1715L 17" Touchscreen Monitor (Discontinued April 2006)
Overview
The 1715L touchmonitor is designed, developed and built to provide the most cost-effective touch solutions for system integrators and VARs. It packs Elo quality and reliability into an integrated, affordable touchmonitor.
Other features.
- Entry-level monitor with Elo quality
- "Designed for touch" features such as a stable tilt base
- Long-lasting product cycle
- Available with IntelliTouch® Surface Wave Technology
- Sealed touchscreen
- Dual serial/USB interface
- Removable base and VESA mounting option
- Mounting holes on base bottom for tabletop security
- Controls on the side rather than the front, plus lockout function for public use
- Digital on-screen display (OSD)
- Worldwide agency approvals
Presupuesto
-
Técnico
Número(s) de Parte(s)
IntelliTouch (Antiglare, Worldwide) - C20990-000
Color del empaque
Gris oscuro
Tecnología y capacidad táctil
SAW (IntelliTouch® de ondas acústicas de superficie) - Táctil simple
Tamaño de la diagonal
17'' diagonal, matriz activa TFT LCD (LED)
Relación de aspecto
5:4
Área activa
13.3" x 10.6" / 338mm x 270mm
Resolución
1280 x 1024
Otras resoluciones disponibles
1280 x 1024 at 60 or 75 Hz
1280 x 960 at 60 Hz
1152 x 864 at 75 Hz
1024 x 768 at 60, 65 Hz (Sun), 70 or 75 Hz
832 x 624 at 75 Hz (Mac)
800 x 600 at 56, 60, 72 or 75 Hz
720 x 400 at 70 Hz
720 x 350 at 70 Hz
640 x 480 at 60, 66 Hz (Mac), 72 or 75 HzÁngulo de visión
Horizontal: ±70° or 140° total / Vertical: 63°/60° or 123° total
Cantidad de colores
16.2 millones
Brillo (tipico)
LCD panel: 250 nits
IntelliTouch: 230 nitsTiempo total de respuesta (tipico)
25 msec
Radio de contraste
450:1
Interface táctile
Dual serial/USB: C20990-000
Pantalla en pantalla (OSD)
Digital OSD
Controles de usuario
OSD buttons: menu, up, down, select, power
OSD: contrast, brightness, H/V position, RGB (color temp), clock, phase, recall,
Languages: English, German, Spanish, Japanese, French
OSD disable/enable: power, OSD menuFormato de entrada de video
RGB analog only
Entrada del conector para video señal
Mini D-Sub 15-Pin VGA type
Consumo de energía (típico)
50 W max
Fuente de alimentación
Internal, with jack to accept power from optional external brick
Voltaje de entrada
AC: 100-240 VAC, 50/60 Hz; DC: +12 VDC ±5%
Frecuencia de entrada
Horizontal: 31.5-80 kHz / Vertical: 56.3-75 Hz
Sync Types
Separate horizontal and vertical sync, composite sync and sync-on-green
Dimensiones del monitor (con soporte)
15.4" x 8.0" x 14.4" / 391mm x 203mm x 366mm
Peso sin empaque
15.2 lbs / 6.9 kg
Peso con empaque
21.2 lbs / 9.6 kg
Temperatura de operación
0°C to 40°C
Temperatura de almacenamiento
-20°C to 60°C
Humedad
Operating: 20%-80%
Storage: 10%-90%
noncondensingMTBF - Tiempo medido entre fallos (medida de confiabilidad de un dispositivo o sistema)
50.000 horas demostradas
Opciones de montaje
Threaded-through mounting holes, under base
Removable base, 100 mm VESA mountGarantía
3 años
Vida de la lámpara de contraluz
Typical 30,000 hours to half brightness
Aprobaciones y declaraciones reglamentarias
UL, cUL, FCC, CE, TÜV-GS, VCCI, IC, C-Tick
Cables de energía
A North American power cable and a European power cable are included. For touchmonitors being shipped to the United Kingdom, add a UK power cable at no cost by specifying
Elo p/n: D20295-000.Caja de fuente de energía opcional
Elo p/n: E714990, available at additional cost. Power cables for power brick, also available at additional cost:
United States: Elo p/n: E61011-000
European: Elo p/n: D21505-000
United Kingdom: Elo p/n: 276875-000Cables táctiles/de video
Detachable touch and video cables are included.
Periféricos opcionales
Lector de banda magnética (MSR gris oscuro) - Elo P/N: E963462
